Eaton库柏Cooper/Raxton防爆转接头（90°Swivel Adaptor Male to Female）

Eaton/Cooper/Capri/Raxton/Redapt/CEAG cable glands
Eaton库柏代理商：上海颐品自动化科技有限公司 关键词：Eaton防爆戈兰，Cooper防爆葛兰，Capri防爆格兰；Raxton防爆连接件，Redapt防爆变径，防爆呼吸阀等
关键词：Eaton防爆格兰，Cooper防爆格兰，库柏防爆格兰，Cooper防爆箱；
Capri防爆格兰，Raxton防爆变径，Redapt防爆变径堵头，Raxton防爆呼吸阀

英国Raxton防爆转接头（ 90 Degree Swivel Adaptor Male to Female）

CMP防爆格兰代理商: 上海颐品自动化科技有限公司

关键词：Eaton防爆格兰，Cooper防爆格兰，库柏防爆格兰，Cooper防爆箱；
Capri防爆格兰，Raxton防爆变径，Redapt防爆变径堵头，Raxton防爆呼吸阀

90° Degree Swivel Adaptor Male to Female Brass ATEX/IECEx/INMETRO/Exd/Exe

The 90° swivel adaptor (types FP, FQ, FR) has been designed to allow a full 360° choice of cable entry/exit positions.
This enables the installer to run the cable in any direction which greatly improves ease of installation in confined or
difficult situations. The cable entry/exit can be aligned without the over or under torque compromise imposed by
the direction of the cable. The in-line type (types FA, FC, FD) allows independent connection at both ends.

Certifications and compliances ：

Code of protection categories ATEX: I M2, Ex d IMb, Ex e I Mb, (not aluminium) or IIGd Ex d IIC Gb, Ex e IIC Gb, Ex tb IIIC Db

IECEx: Ex d Ex e IIC Gb, Ex d Ex e IM (not aluminium), Ex tb IIIC Db, IP 6X

INMETRO: Ex d IIC Gb, Ex e IIC Gb, Ex d I Mb, Ex e Mb, Ex tb IIIC Db IP6X

Compliance standards ATEX: EN 60079-0, EN60079-1, EN 60079-7, EN 60079-31

INMETRO: ABNT NBR IEC 60079-0, ABNT NBR IEC 60079-1, ABNT NBR IEC 60079-7,
ABNT NBR IEC 60079-31 IECEx: IEC 60079-0, IEC 60079-1, IEC 60079-7, IEC 60079-31

Certificate details ATEX: Sira 10ATEX1056U, ITS16ATEX101337U
IECEx: IECEx SIR 10.0025U, IECEx ITS16.0010U INMETRO: NCC 12.0764X

Temperature Temperature range: -20°C to +60°C Exd, -50°C to +200°C Exe
Ingress protection (IP): Independently tested to IP66 / IP68 when fitted in accordance to manufacturer’s instructions.

Eaton/Cooper/Capri/Raxton/Redpt防爆格兰，防爆变径等，防爆呼吸阀等

Hazardous Area Cable Glands-ATEX IECEX，Exe，Exd Group II

Capri防爆格兰代理商：上海颐品自动化科技有限公司

Eaton/Cooper/Capri/Raxton/Redpt防爆格兰，防爆变径等，防爆呼吸阀等

关键词：CMP防爆格兰，CMP防爆变径，CMP防爆堵头，CMP防爆呼吸阀

CMP防爆格兰等产品规格书及相关证书-请咨询上海颐品自动化科技有限公司

CMP防爆格兰代理商: 上海颐品自动化科技有限公司
